The PureStream™ VIP-200H II HDMI & USB/KM over IP Extension System offers 1080p signal distribution over the network with enhanced features including video wall processing, built-in scaling functionality, and faster switching speeds. Local and remote units can be connected together for point-to-point extension over distances up to 492 ft (150 meters), as well as a point-to-many, many to point, matrix connectivity and up to an 8×8 video wall using the VPX IP Video Management Software.

Key Features
    • Full HD/1080p@60Hz support
    • HDCP 1.4 compliant
    • Video wall processing (up to 8×8 configuration)
    • Built-in scaler (Rx) – pass through or lock output resolutions
    • Rs-232 extension/steerable distribution
    • USB 2.0 Keyboard/Mouse Extension
    • Audio insertion and extraction
    • Bi-directional RS-232 and IR control
    • Loop-out on transmitter (encoder)
    • Point to point, Distribution, Switching, and Matrix systems
    • Compatible with VPX IP Video Management Software
Performance
Supported Distance Up to 492ft (150m)
Supported Resolutions Up to 1080p, 1920x1200@60Hz
Compliance HDCP 1.4
Supported Audio Formats Up to 7.1 LPCM 192Khz / Dolby True HD / DTS-HD Maste
Ir Receiver(Internal) 20-60Khz/ ±45°/5M
Ir Emitter(External) 3.5mm Stereo Phono Jack 20-60Khz/ ±45°/5M
Power Supply DC 5V 2000mA
Connections
Input Type(s) (1) HDMI Type A (1) 3.5mm Stereo Phone Jack (line-in) (1) USB 2.0 Type B (1) RS-232 DB9 Female
Output Type(s) (1) HDMI Type A (1) 3.5mm Stereo Phone Jack (line-out) (1) Gigabit RJ45
Ir Receiver(Internal) 20-60Khz/ ±45°/5M
Enclosure
Product Dimensions 5.51inch x 4.92inch x 1.18inch
Product weight 0.84 lbs.
Warranty
Warranty Limited Warranty (3-Years)
