The BS-6000 is a 6×1 Full HD Broadcast Switch with Camera Control and Recording. This feature-packed high-performance broadcast switch features chroma/luma key, PTZ camera control, on board recording, and on board media playback. The BS-6000 also includes (10) transition effects, an audio mixer, Picture-in-Picture (PIP), Picture-Outside-of-Picture (POP), and multi-view output. With PTZ camera control, onboard recording, and media playback there is no need to have additional devices to perform these functions. PureLink’s renowned Motore scaling engine built-in to the BS-6000 provides low latency and the highest quality video scaling in the industry.
With all of these built-in features, you will have everything you need in a powerful compact solution, ideal for house of worship, rental, hotel av, conferences, seminars, and more.
6×1 Full HD Broadcast Switch with Camera Control and Recording
- Supports up to 1080p60 resolutions
- (4) 3G-SDI inputs
- (2) inputs that can be set to HDMI, DVI, VGA, or USB
- (2) USB inputs for onboard media playback with transport controls
- PTZ of up to (2) cameras supporting VISCA or PELCO control standards
- XLR and RCA audio inputs with (3) channel fader mixer
- On board SD card recording with transport controls
